Devil’s Lake Embankments Phase 2B / East Ditch Pump Station

Raise 13,000 LFof embankments along Devil’s Lake from elevation 1461.2 to 1468.2. Construct a new interior drainage pump station/gatewell and remove and demo the existing pump station. Pump station consists of structural headwall with 72” diameter inlet piping capable of discharging 280,000 GPM through eight 42” HDPE discharge lines connected to a gatewell structure constructed within an earthen cofferdam 300′ into the lake. Install new primary and secondary power transformers and ductbank, elevated concrete deck with steel joist and deck for pump station, electrical components and pumps, automated grease lubrication system for main pumps, 72” electrically actuated steel gates, 10-ton bridge crane, and overhead suspended grab rake system for solids collection.

Location: Devils Lake, ND
Cost: $ 47.7M
Owner: USACE St Paul District
Designer: USACE
Construction Period: 03/2011 – 07/2013

Fall Creek Fish Facility

Construct a new adult fish collection facility, upgrade and tie in to the existing fish facility to comply with current environmental criteria, and provide a safe working environment for the end user. This effort includes a new concrete fish ladder, pre-sort structure, fish crowder, transport flumes, anesthetic tank, recovery tank, false weir, brail assembly, head box dewatering flume, post-sort structure, pre-engineered steel structure & independent mezzanine with lower access platform, installation of complex mechanical systems, tie in of large diameter carbon steel water supply and return piping, fish handling equipment, demolition and modification of the existing fish ladder, associated electrical installations, asphalt/concrete paving, and landscaping.

  • Cost: $14,336,488
  • Owner: USACE Portland District
  • Designer: USACE Portland District
  • Construction Period: 08/2016 - 07/2018

Manning Crevice Bridge Replacement

Manning CreviceCM/GC project to replace a 300’+ span double tower cable-stayed, suspension, vehicular bridge over the Salmon river with a single tower cable-stayed, suspension bridge.



  • Cost: $9,640,000
  • Owner: WFHL
  • Designer: Atkins
  • Construction Period: 06/14 - 05/18

Minidoka Dam Modifications

Construct a south gated spillway,  north and south mass concrete dikes, north and south side canal headworks, north and south mass concrete overflow spillways, and modify the existing north gated spillway.  The spillway dike is 2,000 feet long, the 3 radial gate structures contain 16 radial gates each 20’ wide and 20’ to 24’ tall.  Demolish the existing overflow spillway and canal headworks; excavate foundations, spillway approach channel, and spillway outlet channel, install government-furnished radial gates, gate hoists, and associated equipment; furnish and install fencing, gates, railing, stairs, and gantry crane and associated rails.

  • Cost: $24,968,807
  • Owner: Bureau of Reclamation (USBR)
  • Designer: USBR
  • Construction Period: 09/2011 – 03/2015

Design-Build Missile Procedure Training Facility

Design-Build  LEED Gold certified Missile Procedures Training Operations Facility to manage and direct missile operations includes briefing rooms, simulators, warehouse areas and non-food storage.

  • Cost: $9,505,000
  • Owner: USACE Omaha District
  • Designer: Tetra Tech / WJA
  • Construction Period: 01/2010 - 09/2011

Fort Peck Water Treatment Facility

Construct new treatment plant process building which houses 8 cast in place concrete filter boxes, a single-level chemical feed and storage area, electrical load center, operations & administration area, garage/shop maintenance area, 30-foot deep drain pump station, along with associated access roads, sitework, and landscaping irrigation water system, potable water system, sanitary sewer system, equipment installation, plumbing, instrumentation & controls, heating & ventilation, and electrical.

  • Cost: $27,287,000
  • Owner: Fort Peck Assiniboine and Sioux Tribes
  • Designer: Morrison - Maierle, Inc
  • Construction Period: 06/2009 - 12/2011

Rehabilitate Mores Creek Bridge

Rehabilitate Pier 4 footing (including pressure grouting and rock armoring), expansion joint and bridge deck, install guardrail,  bridge railing,  seismic restrainers, bearing cap extension, and paint steel truss superstructure.



  • Cost: $3,200,000
  • Owner: ITD
  • Designer: HDR
  • Construction Period: 10/2011 - 11/2011
